Inclined Duct Fluid Simulation

Fluid Flow Simulation for Inclined Duct in Steel making plant , which have high heat convection in outside surface (for air flow 700 to 900 degree centigre ) and heat transfer coefficient = 214 w/m2.oC )

also internal pipe water flow with flow rate = 960 m3/hr
